Center Lathe

HEYLIGENSTAEDT EV400/2000

EV400/2000
conventional
Order now

Details

  • Number2086-744
  • ManufacturerHEYLIGENSTAEDT
  • TypeEV400/2000
  • Controlconventional
  • Year1971
  • Delivery timeimmediately
  • Freight basisex Site
  • LocationHamburg
  • OriginGermany

Technical details

  • turning diameter over bed900 mm
  • turning diameter over slide rest800 mm
  • centre distance2.000 mm
  • turning diameter1.200 mm
  • turning diameter in the gap1.460 mm
  • max. width of the adjustable bend900 mm
  • spindle bore85 mm
  • Turning rate14-710 min-1
  • Connected load frequency380 V
  • Dimensions of the machine (L x W x H), approx.4.705 x 2.060 x 2.000 mm
  • weight of the machine approx.6.000 kg

Equipment

  • 4 fold tool clamping system, HEIDENHAIN three-axis digital readout, Three jawchuck FORKARDT F400, Vibration damping elements

Description

The machine is in very good condition considering its age. The main spindle box
was completely overhauled approx. 10 years ago. The vibration-damping elements are
included in the scope of delivery. The machine is from the original owner. The
previous owner used the machine for the production of their own products (not a
contract manufacturer)
